Medium Duty Flat Belt-ABEZ

Category: EZ Logic Conveyor

The Model ABEZ is a horizontal live roller conveyor designed for applications that require accumulation of products without a build-up of line pressure. Singulation feature allows products to be easily removed from any location on conveyor.

Features

Bed	6-1/2" deep x 12 ga. formed steel channel frame powder painted
Rollers	1.9" dia. x 16 ga.galvanized tread rollers spaced every 3" and an EZLogic® Accumulation Module located in each zone
Overall Frame Widths	18", 20", 22", 24", 26", 28", 30", 34", 36", 40", & 42"
Drive	Center Drive (standard)
Motor	1/2 HP standard - 2 HP max
Supports	Adjustable Floor Supports Available
Capacity	Maximum load per linear foot of conveyor; 150 lbs. No minimum load
Other	Accumulation Zones - 12", 18", 24", 30", & 36" Long Air Controlled
Availability	1 Week (Contact for sizes available)

Product Specifications
